R22 Sanyo Hermetic Compressor
Model Number:C-SB303H8A
Type:Refrigeration Compressor
Color:Black
Place of origin:Japan
Description
Black R22 Sanyo compressor C-SB303H8A for air conditions
Sanyo C-SB scroll compressor is an electric compressor with internal high and low pressure type totally enclosed structure, and the upper part becomes high pressure and the lower part becomes low pressure by high and low pressure partition. The Sanyo compressor is vertical, with the motor on the lower side and the compressor on the upper side. The electric motor is fixed with the shell hot mount, the upper and lower bearings are welded to the shell, and the upper bearing is fixed with the compressor part (fixed scroll, dynamic scroll, etc.). In addition, the lead wire of the motor through the shell part (terminal block) uses a glass-sealed airtight terminal.
Product Introduction：
Brand Name:Sanyo
Model Number:C-SB303H8A
Type:Refrigeration Compressor
Color:Black
Place of origin:Japan
Displacement (m3/rev):66.8
Nominal capacity(kW):11.8
Nominal capacity(kBTU/H):40.3
COP(W/W):3.23
Product details:
SANYO AC compressor,SANYO AC air conditioning compressor C-SB303H8A | |
Brand | Sanyo |
Model | C-SB303H8A |
Production Capacity | 2000 Piece/Pieces per Month |
Refrigerant | R22 |
Voltage/herz | 380-415V/50Hz;440-460V/60Hz |
Out put(HP) | 4 |
Displacement(m3/rev) | 66.8 |
Compressor code | 809 840 88 |
Nominal capacity (kW)50Hz | 11.8 |
Nominal capacity (kBTU/H)50Hz | 40.3 |
COP (W/W)50Hz | 3.2 |
COP(BTU/Wh)50Hz | 11.0 |
Nominal capacity (kW)60Hz | 14.4 |
Nominal capacity (kBTU/H)60Hz | 49.2 |
COP (W/W)60Hz | 3.27 |
COP(BTU/Wh)60Hz | 11.2 |
Outline Graph Code | A |
Sanyo refrigeration compressor Freon collection method：
1. Open the air conditioner, in the case of Sanyo scroll compressor work, unscrew the hexagonal cap of the large and small tubes of the air conditioner.
2. Find the corresponding hexagonal cap, first close the valve of the small tube, and then close the valve of the large tube after more than 10 seconds.
3. To ensure that the Sanyo compressor speed is normal, the two valves are closed, and then stop the air conditioner can be.
FAQ:
(1). What is your delievery time?
---The time of delievery is 3-10 working days after payment.
(2). What is the price?
---The price is depends on the quantity.
(3). What is the advantages of Sanyo scroll compressor?
---Sanyo scroll compressor has the advantages of high energy efficiency, low noise, and high reliable operation.
